1.Speed: 40-200rpm for all models
2.Digital panel with speed and time control
3.Working pan size 25X25cm,with max load 2KG
4.Continuous operation and timed operation range 1min-23h59min
5.DC brushless motor, safe, long life and free of maintenance. Operating silent and stable
| Specification | OS-20F | OS-40F | LS-40F | OS-20Pro | OS-40Max | LS-40Max |
|---|---|---|---|---|---|---|
| Motor Type | Brushless motor | Brushless motor | Brushless motor | Brushless motor | Brushless motor | Brushless motor |
| Plate Size | 250×250 mm | 320×320 mm | 320×320 mm | 250×250 mm | 320×320 mm | 320×320 mm |
| Turn | Circular | Circular | Linear & reciprocating | Circular | Circular | Linear & reciprocating |
| Max Load | 2 kg | 3 kg | 3 kg | 2 kg | 5 kg | 5 kg |
| Orbit Diameter | 20 mm | 20 mm | Linear & reciprocating 20 mm | 20 mm | 20 mm | Linear & reciprocating 20 mm |
| Speed Range | 40–200 rpm | 40–200 rpm | 40–200 rpm | 40–200 rpm | 40–200 rpm | 40–200 rpm |
| Timing Range | 1 min – 23h 59min | 1 min – 23h 59min | 1 min – 23h 59min | 1 min – 23h 59min | 1 min – 23h 59min | 1 min – 23h 59min |
| Voltage | 100–240V, 50/60Hz | 100–240V, 50/60Hz | 100–240V, 50/60Hz | 100–240V, 50/60Hz | 100–240V, 50/60Hz | 100–240V, 50/60Hz |
| Allowable Ambient Temp | 5–40°C, 80% RH | 5–40°C, 80% RH | 5–40°C, 80% RH | 5–40°C, 80% RH | 5–40°C, 80% RH | 5–40°C, 80% RH |
| Size | 355×260×100 mm | 435×330×140 mm | 435×330×140 mm | 355×260×135 mm | 435×330×140 mm | 435×330×140 mm |
| Net Weight | 3.65 kg | 3.75 kg | 4 kg | 4.85 kg | 8.1 kg | 8.1 kg |
