| Technical Specifications | |
| Optical System | Infinity color corrected optical system |
| Viewing Head | Inverted 45° monocular head, interpupillary distance 54–75mm |
| Erect image, 30° inclined gemel trinocular head, interpupillary distance 54–75mm, splitting ratio R:T = 100:0 or 0:100 | |
| Erect image, 30° inclined gemel trinocular head, interpupillary distance 54–75mm, splitting ratio R:T = 90:10 or 100:0 | |
| 55–75mm eyepiece adjustable, erect image, infinity hinged trinocular head | |
| Eyepiece | WF10x/22mm high eye-point plan wide field eyepiece |
| PL10X22mm high eye-point plan wide field eyepiece | |
| Objective | Infinity-Corrected Flat-Field Achromatic Objective (4X, 10X, 20X, 40X, 60X, 100X) |
| Infinity-Corrected Flat-Field Achromatic Positive Phase Contrast Objective (10X, 20X, 40X, 100X) | |
| Infinity-Corrected Semi-Apochromatic Fluorescence Objective (4X, 10X, 20X, 40X, 100X) | |
| Nosepiece | Quintuple nosepiece |
| Frame | Coaxial focus system with upper limited and tension adjustment |
| Coarse range 30mm, fine precision 0.002mm | |
| Stage | Mechanical stage 76x50mm |
| Stage size 180x155mm | |
| Double plate mechanical stage, movable range 75x50mm | |
| Condenser | N.A.1.25 Abbe condenser |
| N.A.1.25 dark field condenser | |
| Single-band Fluorescent Illumination | Fluorescence filter set center wavelength 470nm |
| G1 fluorescence color filter set | |
| B4 fluorescence filter set | |
| Reflected Fluorescence Illumination System | Six-hole disc reflected fluorescence illuminator |
| 100W mercury lamp housing | |
| Transmitted Illumination System | Halogen lamp transmitted illumination |
| Optional 6V 30W halogen bulb | |
| CCD Adapter | 0.35X, 0.5X, 0.65X, 1X C-mount adapter |
| Others | Color temperature transition / green contrast / yellow neutral filter |
| ND25 / ND50 | |
