Zoom Stereo Microscope, 0.65~5.3x, 1:8.1, Trinocular, Up/Down 3W LED
Powered By Safety Low Voltage Charger
Input Wide Voltage 100V-240V, Output 5V1A, Support Power Bank Supply For Outdoor Use
|
Items |
SLV-53 Series Zoom Stereo Microscope |
53-1 |
53-2 |
53-3 |
|||||||
|
B |
BL |
B |
BL |
T |
TL |
B |
BL |
T |
TL |
||
|
Head |
Binocular Head Inclined 40° |
● |
● |
|
|
|
|
|
|
|
|
|
Binocular Head Inclined 35° |
|
|
● |
● |
|
|
● |
● |
|
|
|
|
Trinocular Inclined 35°, Light Split Switch E100:P0/E0:P100 |
|
|
|
|
● |
● |
|
|
● |
● |
|
|
Trinocular Upgrade To Light Split Fixed E50:P50 |
|
|
|
|
○ |
○ |
|
|
○ |
○ |
|
|
Eyepiece |
Eyepiece Tube Dia.30mm, High Eyepoint, Diopter Adjustable |
● |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
WF10x/22mm, Pair |
● |
● |
|
|
|
|
|
|
|
|
|
|
WF10x/23mm, Pair |
|
|
● |
● |
● |
● |
|
|
|
|
|
|
WF10x/24mm, Pair |
|
|
|
|
|
|
● |
● |
● |
● |
|
|
Zoom Lens |
0.7x~4.5x, Zoom Ratio 1:6.5 |
● |
● |
|
|
|
|
|
|
|
|
|
0.68~4.7x, Zoom Ratio 1:6.8 |
|
|
● |
● |
● |
● |
|
|
|
|
|
|
0.65~5.3x, Zoom Ratio 1:8.1 |
|
|
|
|
|
|
● |
● |
● |
● |
|
|
Zoom Knob |
With Magnifying Stop Pin |
|
|
● |
● |
● |
● |
● |
● |
● |
● |
|
Magnification |
7.0x~45x, Up to 3.5x~180x By Optional Auxiliary Lens |
● |
● |
|
|
|
|
|
|
|
|
|
6.8x~47x, Up to 3.4x~188x By Optional Auxiliary Lens |
|
|
● |
● |
● |
● |
|
|
|
|
|
|
6.5x~53x, Up to 3.25x~212x By Optional Auxiliary Lens |
|
|
|
|
|
|
● |
● |
● |
● |
|
|
W.D. |
Working Distance 108mm, With Standard 1x Lens |
● |
● |
● |
● |
● |
● |
● |
● |
● |
● |
|
Stand |
Large Track Stand, Base Size 33x30cm, Track Stand Focusing Range 80mm No Light Source |
● |
|
● |
|
● |
|
● |
|
● |
|
|
Large Track Stand, Base Size 33x30cm, Track Stand Focusing Range 80mm Up/Bottom 3W LED, Power By Safety Low Voltage Charger |
|
● |
|
● |
|
● |
|
● |
|
● |
