0.67x-4.5x Zoom Magnification Zoom Ratio 1:6.7
• Zoom Knob with Click Stop Switch & Magnification Lock
• 45° Inclined Binocular & Trinocular Head with Working Distance 110mm
• Pole & Track Stand with Coarse Focusing Range 50mm
• Transmit & Reflect LED Light Source Available
| Serie Zoom Stereo Microscope | ||||||||
| Head | Binocular Head, 45º Inclined, Inter-pupillary Distance 52-76mm | -B4 | -B5 | -BL1 | -BL3 | -ST2 | -STL 1 |
-STL 2 |
| Trinocular Head, 45º Inclined, Inter-pupillary Distance 52-76mm | -B4T | -B5T | -BL1T | -BL3T | -ST2T | -STL 1T |
-STL 2T |
|
| Eyepiece | High-Eyepoint Wide Field Plan Eyepiece PL10x/22mm, Diopter Adjustable | ●● | ●● | ●● | ●● | ●● | ●● | ●● |
| High-Eyepoint Wide Field Plan Eyepiece PL15x/16mm, Diopter Adjustable | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| High-Eyepoint Wide Field Plan Eyepiece PL20x/12mm, Diopter Adjustable | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Lens | 0.67-4.5x, W.D.=110mm, With Click Stop & Magnfication Lock On Zoom Knob | ● | ● | ● | ● | ● | ● | ● |
| Auxliary Objective | 0.3X/WD287mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
| 0.4X/WD217mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 0.5X/WD177mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 0.75X/WD120mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 1.5X/WD47mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 2X/WD26mm | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Focus | Bracket ST70A1 With Coarse Focusing Knob, Focus Range 50mm | ● | ● | ● | ● | ● | ● | ● |
| Base | B4 Pillar Stand, No Light Source | ● | ||||||
| B5 Pillar Large Black Flat Stand, No Light Source | ● | |||||||
| BL1 Track Stand, With LED Light, Reflect 15 LEDs, Transmit 75 LEDs | ● | |||||||
| BL3 Pillar Stand, With LED Light, Reflect 15 LEDs, Transmit 75 LEDs | ● | |||||||
| ST2 Pillar Large White Flat Stand, No Light Source | ● | |||||||
| STL1 Single Arm Boom Pillar Stand, No Light Source | ● | |||||||
| STL2 Double Arm Boom Pillar Stand, No Light Source | ● | |||||||
| C-Mount | 0.35X C-mount | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
| 0.5X C-mount | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 0.65X C-mount | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| 1.0X C-mount | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Packing | Inner Foam + Strong Carton Box | ● | ● | ● | ● | ● | ● | ● |
